Bronze needle valve 482 with bronze body, CW614N brass bonnet, seat, and shaft. PTFE packing gland, BSP female/female connections. For precise fluid control in group 2 fluids, operating from -10°C to 180°C up to 25 bar.
| Specification | Value |
|---|---|
| DN inches NPS | 1/4'' |
| DN metric | 8/13 |
| Bonnet material | Brass CW614N |
| Type of seat | parallel |
| Thread standard | ISO 228-1 |
| Tightness test standard | EN 12266-1. Rate A |
| Opening device | Handwheel |
| Centering ring | Yes |
| Shaft/stem matérial | Brass CW614N |
| Opening device/signal | Manual |
| DN | DN8 - 1/4'' |
| Face to Face (mm) | 46.0 |
| Sealing | Metal / Metal |
| Fluid | Cold water |
| Body material | Bronze |
| Bore | Reduced |
| PS (bar) | 25 |
| Connections | BSP FF |
| Seats | Brass |
| TS max (°C) | 180 |
| TS min (°C) | -10 |
| Warranty period | 2 years |
| Type of stem | Rotating |
| Plug material | Brass CW614N |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Bronze Reduced 1/4'' | 482002 | S1010663 |
€26.49
(excl. btw)
|
add to cart |
| BSP FF Bronze Reduced 3/8'' | 482003 | S1010664 |
€26.50
(excl. btw)
|
add to cart |
| BSP FF Bronze Reduced 1/2'' | 482004 | S1010665 |
€29.94
(excl. btw)
|
add to cart |
| BSP FF Bronze Reduced 3/4'' | 482005 | S1010666 |
€43.87
(excl. btw)
|
add to cart |
